Sno*Melter Mats

Sno*Melter Mats



No More Shoveling, Salting, or Plowing!


Some of the most unpleasant winter weather conditions are caused by snow, ice and freezing rain.  Not only dangerous, exterior surfaces typically need to be cleared by plowing, shoveling or chemically treating walkways and other surfaces. Often, these "remedies" can produce damaging effects on property, and are typically unreliable, time consuming and costly.

For a more effective way to ensure a clear, dry pavement, consider Sno*Melter by Easy Heat.  Snow melter mats and controllers create an automatic electric system that melts snow and freezing rain on contact, reducing the inevitable costs and potentially damaging effects of traditional snow removal methods.  UL Listed, Sno*Melter is highly efficient and considerably more economical than most other snow and ice removal methods, since it only operates for relatively short periods of time each winter.  EasyHeat Sno*Melter mats can be installed in a variety of applications, including driveways, ramps, walkways, entry ways, sidewalks, patios, loading docks, stairs, and outdoor kitchens.

Sno Melter mats are installed about 2" below the surface of asphalt, under pavers, or in concrete, and connect up to standard 240 voltage.  At 50 Watts/Sqft., Sno*Melter mats are stocked in widths of 18" or 30", and lengths of up to 30 feet.  All mats are supplied with 20' cold leads as standard.  With the use of specialized snow melting controllers and magnetic contactors, multiple mat and zone systems can be designed.

For stair tread applications, specifically designed Easy Heat Sno*Melter Step mats are also available in 240 Volt at 50 Watts/Sqft., and stocked in  3' or 6' tread widths with 8" risers.  Steps mats are supplied with 10' cold leads standard.


18 Inch Wide Sno*Melter Mats
240 Volt Models with 20 Ft. 14 GA (20A) Cold Leads

Model No.
Dimensions
Watts
Amps*
G05X18-240-50-20A
5 ft. long x 18 in. wide
375 Watts (50 Watts/Sq ft.)
1.6
G06X18-240-50-20A
6 ft. long x 18 in. wide450 Watts (50 Watts/Sq ft.)1.9
G07X18-240-50-20A
7 ft. long x 18 in. wide525 Watts (50 Watts/Sq ft.)2.2
G08X18-240-50-20A8 ft. long x 18 in. wide600 Watts (50 Watts/Sq ft.)2.5
G09X18-240-50-20A9 ft. long x 18 in. wide675 Watts (50 Watts/Sq ft.)2.9
G10X18-240-50-20A10 ft. long x 18 in. wide750 Watts (50 Watts/Sq ft.)3.2
G15X18-240-50-20A15 ft. long x 18 in. wide1125 Watts (50 Watts/Sq ft.)4.7
G20X18-240-50-20A20 ft. long x 18 in. wide1500 Watts (50 Watts/Sq ft.)6.3
G30X18-240-50-20A30 ft. long x 18 in. wide2250 Watts (50 Watts/Sq ft.)9.4

36 Inch Wide Sno*Melter Mats

240 Volt Models with 20 Ft. 14 GA (20A) or 10 GA (20B) Cold Leads

Model No.
Dimensions
Watts
Amps*
G04X36-240-50-20A
4 ft. long x 36 in. wide
600 Watts (50 Watts/Sq ft.)
2.5
G05X36-240-50-20A
5 ft. long x 36 in. wide750 Watts (50 Watts/Sq ft.)3.2
G10X36-240-50-20A
10 ft. long x 36 in. wide1500 Watts (50 Watts/Sq ft.)6.4
G15X36-240-50-20B15 ft. long x 36 in. wide2250 Watts (50 Watts/Sq ft.)9.4
G20X36-240-50-20B20 ft. long x 36 in. wide3000 Watts (50 Watts/Sq ft.)12.6
G30X36-240-50-20B30 ft. long x 36 in. wide4500 Watts (50 Watts/Sq ft.)18.8

Stair Tread Sno*Melter Mats
240 Volt Models with 10 Ft. 14 GA (20A) Cold Leads


Model No.
Dimensions
Watts
Amps*
2M2-3-0X8
2 Steps, 3' x 8" Tread
200 Watts
0.9
2M2-6-0X8
2 Steps, 6' x 8" Tread400 Watts
1.7
3M2-3-0X8
3 Steps, 3' x 8" Tread300 Watts
1.3
3M2-6-0X83 Steps, 6' x 8" Tread600 watts
2.5


18" Wide Sno*Melter Mats

36" Wide Sno*Melter Mats

Sno*Melter Step Mats
